Gallium arsenide (GaAs) is a compound of the elements gallium and arsenic. It is a III-V direct bandgap semiconductor with a zinc blende crystal structure.TTV (um) - <10Surface Finish - Epi ReadyPacking = Individually Packed in inert atmosphere
GAS 369 (OTTO) Gallium arsenide wafers, <100>, diam. × thickness 76.2 mm × 625 mm - used as a substrate material for the epitaxial growth of other III-V semiconductors including: Indium gallium arsenide, Aluminium gallium arsenide and others.
RIDADR UN 1557 6.1 / PGII
Certificate Of Analysis
(For eg. B 1615-0108)
Other Documents
For any quries, please write to us at
7440-21-3
