Sapphire wafers, <100>, dia. x thickness 100 mm x 0.5 mm

Code: SS 1080
38180010
Container
18%
38180010
Container
18%
PackingsPrice (INR)
1 pc POR
10 pc POR
Custom size POR
Packings
Sapphire wafers, <100>, dia. x thickness 100 mm x 0.5 mm, SS 1080, (1)
Enquire
Captcha
Properties
Crystal optics,Glass substrates (BK7 Optical windows)
Sapphire
Orientation <100>
C-axis(0001) to M(1-100)0.2°±0.1°
100 mm
0.5 (±0.025)mm
± 1%
A-Plane±0.3°
30±1mm
<0.3nm
<1.2μm
<10μm
<15μm
<15μm
Class 100 clean room cleaning and vacuum nitrogen packaging
SSP
Description

Wafer in cassette vacuum sealed. Packaging provided for wafers.

Application

SS 1080 (OTTO) Sapphire wafers, <100>, dia. x thickness 100 mm x 0.5 mm - used substrate material for blue, green, ultraviolet and white LEDs.

Safety Information

Information for this product is unavailable at this time.
