Laser Grade Plano Convex Lens, 38.1 mm Dia, Focal Length : 127 mm

Code: LGP009

Synonyms: Plano-Convex Cylindrical Lens (Laser grade)

Focal Length : 127 mm
Bottle / Drum
18%
Focal Length : 127 mm
Bottle / Drum
18%
PackingsPrice (INR)
1 pc POR
10 pc POR
1000 pcs POR
Packings
Laser Grade Plano Convex Lens, 38.1 mm Dia, Focal Length : 127 mm, LGP009, (1)
Enquire
Captcha
Properties
Crystal optics,Laser Grade Optics
BK-7 or Fused Silica
127 mm (± 1%)
38.1 mm (± 2%)
1070 -1080 nm
> Central 85% of diameter
AR coated @1080 nm on both surfaces
> 100 kW/cm2 CW @1080 nm.
< 1 arc min
λ/10
6~7mm
Description

Surface quality 40-20 scratch & dig or better
Wavelength transmission : >85% for 500-2000 nm
>99% for 1080 nm

Application

Plano Convex Cylindrical Lens, are used to focus light to a thin line in laser scanners, spectroscopy, dye lasers, acousto-optics, optical processors and other similar applications.

Safety Information

Safety Information for this product is unavailable at this time.

Documentation

Certificate Of Analysis

(For eg. B 1615-0108)

Other Documents
