Polarizing cube beam splitters, 50.8mm x 50.8mm x 50.8mm+/-0.2mm

Code: PCB 087
for synthesis
50.8mm x 50.8mm x 50.8mm+/-0.2mm
Bottle / Drum
18%
for synthesis
50.8mm x 50.8mm x 50.8mm+/-0.2mm
Bottle / Drum
18%
PackingsPrice (INR)
1 pc POR
10 pc POR
Packings
Enquire
Captcha
Properties
Crystal optics,Polarizing Beamsplitting Cubes
50.8mm x 50.8mm x 50.8mm+/-0.2mm
BK7
λ/4 at λ = 632.8 nm per 25.4mm range, 60-40 scratch-dig
Tp >95%, Rs > 99.5% (approx..)
Tp/Ts > 500:1 (approx.)
Ravg. < 0.5% per surface (approx..) (With multilayer AR coating for 770-800 nm)
0 to 70 oC or nearest std.
0o± 5o or nearest std
≤ 5 arc-min (For transmitted beam) 90 o± 5 arc-min (For reflected beam)
>500mJ/cm2, 20ns, 20Hz, @1064nm
Description

Polarizing beam splitters, such as the Wollaston prism, use birefringent materials, splitting light into beams of differing polarization.

Application

A beam splitter is an optical device that splits a beam of light in two. It is the crucial part of most interferometers.

Safety Information

Safety Information for this product is unavailable at this time.

Documentation

Certificate Of Analysis

(For eg. B 1615-0108)

Other Documents
