Broadband polarizing cube Beam splitter, 12.7 x 12.7 x 12.7 mm

Code: PBSC990
puriss

Box
18%
puriss


Box

18%
PackingsPrice (INR)
1 pc POR
10 pc POR
Packings
Enquire
Properties
12.7 x 12.7 x 12.7 mm

SF 2, NSSK grade, precision annealed optical glass 1

900 nm- 1300 nm

20-10 scratch-dig

0 ° +5 °

12.7 mm

Central diameter, >80% of dimension

2 kW/cm2 CW, 1 J/cm2 with 10 nsec pulses, typical

Transmission of P-polarization (Tp) >90% avg

<= λ /4 at 632.8 nm over the clear aperture

Description

Shape : CUBE
Efficiency
p-polarization transmission (Tp) >90% avg
s-polarization, reflection (Rs) >99.5% avg
Transmitted Beam Deviation: < = 5 arc min
Reflected Beam Deviation: 90° +-5 arc min

Application

A beam splitter is an optical device that splits a beam of light in two. It is the crucial part of most interferometers.
