DKDP crystals (100 x 100 x 20 mm3)

Code: DKDP 006

Synonyms: KDP, DKDP Crystals

9001 / 9002

18%
9001 / 9002


18%
PackingsPrice (INR)
1 pc 8109099.00
5 x 1 pc POR
Custom size POR
Packings
Enquire
Properties
100 x 100 x 20 mm3

± 1 mm

More than 75 mm(Diameter)

Z-cut

± 30 arc min

≤ λ/6 at 633 nm (RMS error)

60 - 40 or better within the aperture

≤ 10 arc sec

AR @ 1054 ± 15 nm; R< 0.2%

96% ± 1%

Description

Deuterated potassium dihydrogen phosphate (KD2PO4) or DKDP single crystals are widely used in non-linear optics as the second, third and fourth harmonic generators for Nd:YAG and Nd:YLF lasers. DKDP crystals are grown by a water-solution method at usual level of deuteration >98%.

Application

DKDP 006 (OTTO) DKDP crystals (100 x 100 x 20 mm3) - used in non-linear optics as the second, third and fourth harmonic generators for Nd:YAG and Nd:YLF lasers. Laser frequency conversion; harmonic generation for high pulse energy, low repetition (<100 Hz) rate lasers; Electro-optical modulation; Q-switching crystal for Pockels cells.

Safety Information

Safety Information for this product is unavailable at this time.

Documentation

Certificate Of Analysis

(For eg. B 1615-0108)

Other Documents

For any quries, please write to us at

qc@ottokemi.com
Technical Services

Our team of R&D Experts and Scientists have expertise in all areas of research of Lab Chemicals, Nano Technology, Life Science, Custom Synthesis, Chromatography, and many others.

Enquire Now

DisclaimerThe above particulars do not release the customer from the obligation to carry out an inspection of goods received.
Not for medical, household or any other uses, for lab use only, Please test before use.


PackingsPrice (INR)
1 pc 8109099.00
5 x 1 pc POR
Custom size POR
