Dielectric coated beam splitter (Multi-layer) 1050-1070 nm

Code: DCBS069
9001 / 9002
18%
9001 / 9002
18%
PackingsPrice (INR)
1 pc 50409.00
10 pc POR
Packings
Dielectric coated beam splitter (Multi-layer) 1050-1070 nm, DCBS069, (1)
Enquire
Captcha
Properties
Crystal optics,Dielectric mirror
Fused silica / BK7
Multi-layer Dielectric coating
50% @ 1050-1070 nm
50% @ 1050-1070 nm
AR coated @ 1050-1070 nm
50 mm
± 1 %
≥ 90% of diameter
8 mm
± 1 %
45 deg
3 deg +/-3
40/20 s/d
1MW/cm2 @ 532nm CW and 2 J/cm2 in 1ns pulsed @ 532nm or better
Safety Information

WGK Germany -

RTECS MD5070000

Documentation

Certificate Of Analysis

(For eg. B 1615-0108)

Other Documents
