Specification Sheet

Silicon window, (190mm x 70 mm) 25 mm Thickness

: Silicon Substrate, Silicon Wafer

: SW009

: Optics

: Si

: Silicon Monocrytalline

: 28.09

: Silicon (Si) Windows manufactured from optical grade silicon are popular for the 1.2 - 7μm spectral region due to their low cost and low density.

: Silicon (Si) optics are widely used in the semiconductor industry; electronic devices, and in photovoltaic applications.


Properties

: Silicon Monocrytalline

: 3.4245±0.0005

: 25 mm

: 180 mm X 60 mm

: 2 regular rings over any 60 mm diameter of clear aperture @ .6328 micron wavelength Chamfering At all the sharp corners and edges

: Both surface with transmission >93% for 3.6-4.9 micron

: Saline water resistant with DLC/HEAR Coating

: +/-0.1mm


Safety Information

Safety Information for this product is unavailable at this time.


PackingsPrice (INR)
1 custom size POR
