Specification Sheet

Silicon optical (mono crystalline) windows, 90 mm dia, 15 mm thick, 99.999%

: Optical grade mono crystalline silicon circular blank

: SW 018

: mono crystalline

: Si

: 99.999%

: 28.09

: Silicon wafers or a “slice” of substrate find applications in the fabrication of integrated circuits, solar cells etc. They serve as a substrate for various microelectronic devices.

: SW 018 (OTTO) Silicon optical (mono crystalline) windows, 90 mm dia, 15 mm thick, 99.999% - used in electronics for the fabrication of integrated circuits and in photovoltaics for conventional, wafer-based solar cells.


Properties

: 90 mm

: ± 0.1%

: 15 mm

: ± 0.1%

: 2-5 μm

: 3.4238

: 99.999%

: 1414 °C

: 964 kg/mm2

: 2.329 gm/cc


Safety Information

WGK Germany 2


PackingsPrice (INR)
1 pc 39996.00
10 pc POR
Custom size POR
