Specification Sheet

Optical Windows AR coated (159.0mm x 19.5mm)

: OW060

: Anti-Reflection Coated High Efficiency Windows used to eliminate back reflections and reduce glare in optical systems.

: Optical Windows are flat, plane-parallel plates that are often used as protective barriers for electronic sensors or detectors from outside environments. Optical Windows should be selected based on the material transmission or mechanical properties of the substrate.


Properties

: Fused silica

: Flat-Flat

: 159.0mm x 19.5mm

: +0/-0.2mm

: 5.0mm

: ±0.2mm

: λ/10@632.8nm

: Better or equal to 20/10 (Scratch/Dig)

: ≤10 arc sec

: Surface 1: AR @ 803 nm with R<0.3%

: Surface 2A: Optically polished

: ≥ 20kW/cm 2 @ 803nm

: Chamfered


Safety Information

WGK 2


PackingsPrice (INR)
1 pc POR
10 pc POR
Custom size POR
