Enquiry

Specification Sheet

Lithium fluoride, optical windows, 50 mm dia, 4 mm thick

: Lithium fluoride optical windows for VUV spectroscopy

: LW 108

: LiF

: 25.94

: Lithium fluoride is an inorganic compound with the chemical formula LiF. It is a colorless solid, that transitions to white with decreasing crystal size. Although odorless, lithium fluoride has a bitter-saline taste. Its structure is analogous to that of sodium chloride, but it is much less soluble in water

: LW 108 (OTTO) Lithium fluoride, optical windows, 50 mm dia, 4 mm thick - used to isolate different physical environments while allowing a light beam to pass.


Properties

: 99.99%

: 50 mm

: ± 1%

: 5 mm

: ± 1%

: ~ 1050 Å (105 nm)

: ≥ 60% in the range 1200 to 1600 Å (120–160 nm) ≥ 90% in the range 1600 – 3000 Å (160–300nm)

: Optical quality double surface polished

: 60/40

: λ/5


Safety Information
  • Skull and Crossbones

Hazard Codes T
Risk Statements 25-32-36/37/38
Safety Statements 22-26-36/37/39-45
RIDADR UN 3288 6.1/PG 3
WGK Germany 3


PackingsPrice (INR)
1 pc POR
5 x 1 pc POR
