Specification Sheet

Lithium fluoride window, 10 x 10 x 2 mm

: LIF 070

: LiF

: 25.94

: Lithium fluoride is an inorganic compound with the chemical formula LiF. It is a colorless solid, that transitions to white with decreasing crystal size. Although odorless, lithium fluoride has a bitter-saline taste. Its structure is analogous to that of sodium chloride, but it is much less soluble in water

: LIF 070 (OTTO) Lithium fluoride window, 10 x 10 x 2 mm - used to isolate different physical environments while allowing a light beam to pass.


Properties

: 10 x 10 mm

: ± 5%

: 2.0 mm

: ± 5%

: [100]

: < λ/4 per 25 mm @ 632.8nm

: <3 arc min

: <40-20 scratch-digs

: > Central 90%


Safety Information
  • Skull and Crossbones

Hazard Codes T
Risk Statements 25-32-36/37/38
Safety Statements 22-26-36/37/39-45
RIDADR UN 3288 6.1/PG 3
WGK Germany 3


PackingsPrice (INR)
1 pc POR
5 x 1 pc POR
