Specification Sheet

Indium tin oxide coated, glass substrate, 100 x 100 x 1.1 mm

: ITO coated, glass substrate

: ITO 180

: In2O3.(SnO2)x

: Indium tin oxide (ITO) is a ternary composition of indium, tin and oxygen in varying proportions. Depending on the oxygen content, it can either be described as a ceramic or alloy.

: ITO 180 (OTTO) Indium tin oxide coated, glass substrate, 100 x 100 x 1.1 mm - used to make transparent conductive coatings for displays such as liquid crystal displays, flat panel displays, plasma displays, touch panels, and electronic ink applications.


Properties

: 100 mm x 100 mm

: ± 0.1%

: 1.1 mm

: ± 0.1%

: = ≤ 10 Ω / sq

: ≥ 90%

: 150 - 200nm

: ≤ 10 nm

: Yes (Silicon dioxide, SiO2)

: ~25 nm

: Soda lime / float glass


Safety Information

WGK Germany 3


PackingsPrice (INR)
1 pc 4995.00
10 pc 39069.00
