Specification Sheet

Indium tin oxide coated, glass substrate, 10 x 10 x 0.7 mm3

: ITO coated, glass substrate

: ITO 063

: In2O3.(SnO2)x

: Indium tin oxide (ITO) is a ternary composition of indium, tin and oxygen in varying proportions. Depending on the oxygen content, it can either be described as a ceramic or alloy.

: ITO 063 (OTTO) Indium tin oxide coated, glass substrate, 10 x 10 x 0.7 mm3 - used to make transparent conductive coatings for displays such as liquid crystal displays, flat panel displays, plasma displays, touch panels, and electronic ink applications.


Properties

: 10 mm x 10 mm

: ± 0.1%

: 0.7 mm

: ± 0.1%

: ≤ 100 Ohms per sq

: > 83%

: 100 - 150 nm

: ≤ 10 nm

: Soda lime / Float glass / Corning glass


Safety Information

WGK Germany 3


PackingsPrice (INR)
1 pc 3006.00
10 pc 27099.00
100 pc POR
