Specification Sheet

Germanium single crystal, 50 mm dia, 50 mm length (N type)

: GW 1908

: N type

: Ge

: 72.64

: Germanium is a chemical element with symbol Ge and atomic number 32. It is a lustrous, hard, grayish-white metalloid in the carbon group, chemically similar to its group neighbors tin and silicon.

: Germanium single crystal, 50 mm dia, 50 mm length (N type) - used at temperatures below 100°C. Germanium’s high density (5.33 g/cm3) should be considered when designing for weight-sensitive systems


Properties

: 99.999%

: 50 mm

: ± 0.1%

: 50 mm

: ± 0.1%

: Cylindrical

: N (donor)

: Cylindrical ground

: (100)

: 2.5 μm RMS or less

: 4x10 8 to 4x10 10/ cm3

: >10 k-Ohm-cm at 77K

: >1ms

: Ranging from 1000 to 5000 / cm2

: 5 x 10 8 /cm 3 or less

: >=10,000 V/cm-sec


Safety Information

RIDADR NONH for all modes of transport WGK Germany 3


PackingsPrice (INR)
1 pc 170199.00
10 pc POR
