β Barium borate single crystal (20 x 20 x 1 mm)

: BBO Crystals

: BBO 108

: Beta barium borate (BBO) crystals are nonlinear optical crystal, used as laser crystals, NOPA crystals or non collinear phase matching.

: Application Second harmonic generation @ 800 nm

Properties

: Crystal optics,β-Barium Borate Single Crystal

: BBO crystal

: 20 x 20 mm

: 1 mm

: ≥ 90%

: No visible scattering paths or centers when inspected by a low power (~50mW) green laser

: ≤ 0.2 mm × 45°

: ≤ 0.1mm

: Type 1

: 29.2°

: 90°

: ≤15 arc min (or 0.25 degrees)

: ≤ λ/8 @ 633 nm

: ≤ λ/8 @ 633 nm

: ≤ 20 arc seconds

: ≤ 5 arc min

: Both side AR

: 400 and 800 nm

: better than 10/5

Safety Information

Safety Information for this product is unavailable at this time.

PackingsPrice (INR)
1 pc POR
5 pc POR
Back Print
