Sapphire wafer, R-plane (1-102), L × W × thickness 10 mm × 10 mm × 0.5 mm

Code: S 4912
PRIME
9001 / 9002
Container
18%
PRIME
9001 / 9002
Container
18%
PackingsPrice (INR)
1 pc 22905.00
10 pc 169029.00
Custom size POR
Packings
Sapphire wafer, R-plane (1-102), L × W × thickness 10 mm × 10 mm × 0.5 mm, S 4912, (1)
Enquire
Captcha
Properties
Crystal optics,Glass substrates (BK7 Optical windows)
R-plane(1-102)
± 0.5°
10 x 10 mm
± 1%
0.5 mm
± 1 %
Epi-polished, Ra < 0.2 nm
Fine ground, Ra = 0.8 μm to 1.2 μm
< 5 μm
< 5 μm
< 5 μm
~ 40/20
Description

Wafer in cassette vacuum sealed. Packaging provided for wafers.
