Substrate Glass Wafers (100 mm x 100 mm x 0.2 mm)

Code: SGW018
9001

Container
18%
9001


Container

18%
PackingsPrice (INR)
1 pc POR
10 pc POR
Custom size POR
Packings
Enquire
Properties
Thin Glass

100 mm x 100 mm

± 0.2 mm

0.2 mm

± 0.020 mm

≥ 90% (@lambda > 350 nm)

20/10

≤ 20 µm

7.2 x 10-6 K-1

≥ 550℃

1.5231@ D-line

6.7

≤ 1 nm Ra

Description

A wafer, also called a slice or substrate, is a thin slice of semiconductor material, such as a create a rough surface to increase their efficiency.

Application

The wafer serves as the substrate for microelectronic devices built in and over the wafer and undergoes many microfabrication process steps such as doping or ion implantation, etching, deposition of various materials, and photolithographic patterning. Finally the individual microcircuits are separated (dicing) and packaged.
