Synonyms: Optical grade mono crystalline silicon circular blank
Silicon wafers or a “slice” of substrate find applications in the fabrication of integrated circuits, solar cells etc. They serve as a substrate for various microelectronic devices.
SW 036 (OTTO) Silicon optical (mono crystalline) windows, 40 mm dia, 10 mm thick, 99.999% - used in electronics for the fabrication of integrated circuits and in photovoltaics for conventional, wafer-based solar cells.
WGK Germany 2
Certificate Of Analysis
(For eg. B 1615-0108)
Other Documents
For any quries, please write to us at
7440-56-4
Germanium optical (mono crystalline) windows, 95 mm dia, 20 mm thick, 99.999%
7789-24-4
Lithium fluoride, optical windows, 40 mm dia, 5 mm thick (with Al coated on one face for working wavelength 1550nm)
7440-21-3
Silicon substrate (single side polished), <100>, P-type, diam. × thickness 1 in. × 300 - 400 μm
Plano convex lens, dia 50.8 mm, focal length 4 cm
