Plane optical window, 150 mm dia, 8 mm thick

Code: PO 360
9001

Container
18%
9001


Container

18%
PackingsPrice (INR)
1 pc POR
10 pc POR
Custom size POR
Packings
Enquire
Properties
Fused silica

150 mm

± 1 mm

8 mm

± 0.5 mm

1064 nm

Normal

AR coating broadband (633-1064 nm) on both surfaces

R<0.25% per surface

40-20 scratch and dig or better

λ/10 @ 633 nm

< 10 arc sec

≥1GW/cm2 @1064 nm

Application

PO 360 (OTTO) Plane optical window, 150 mm dia, 8 mm thick - used widely for Laser optics, optical grade UV Fused Silica windows and lenses, mirror blanks and substrates, wedges, optical beamsplitters and filters, prisms, lightpipes, space and aircraft windows, solar cells, high quality coating substrates etc.
